GoodWe

GoodWe HCA G2 7kW

Name: GoodWe HCA G2 7kW
Brand: GoodWe
Price: 1000 AUD
Availability: InStock

A single-phase charger designed for homes using compatible GoodWe solar and battery systems.

Estimated charger price

around $1,000

Estimated installation

around $700–$1,500

Typical installation estimate for a straightforward home installation. Longer cable runs, switchboard upgrades, three-phase work, trenching or other site requirements can increase the cost.

FIND MY CHARGER Back to chargers

Overview

The GoodWe HCA G2 7kW (GW7K-HCA-20) is a 32 A single-phase smart charger designed to work with compatible GoodWe solar and battery systems. It supports Fast Charging, PV Priority, PV + Battery, Scheduled Charging and Dynamic Load Control, with monitoring and control through SEMS+. The current Australian specification lists a 7.5 m tethered Type 2 cable, Bluetooth, Wi-Fi, RS485 and LAN connectivity, IP66 protection for the charger enclosure and Modbus TCP communication.

Key highlights

7 kW single-phase / 32 A

7.5 m tethered Type 2 cable

Fast Charging, PV Priority and PV + Battery modes

Dynamic Load Control

SEMS+ monitoring and scheduling

Bluetooth, Wi-Fi, RS485 and LAN

Modbus TCP

IP66 charger enclosure

2-year warranty

Best for

Homes already using GoodWe solar/battery systems
Households wanting the highest weather rating (IP66)
Solar homes on a competitive budget
Wall or pole-mounted installations

Not ideal for

— OCPP support is not documented for the Australian HCA G2 specification.

Using this charger at home in Australia

On a suitable installation, this charger can provide up to 7 kW. Actual charging speed also depends on the vehicle's onboard AC charging limit and the configured site capacity.

Where the charger and required monitoring equipment support solar-aware charging, the system can adjust EV charging in response to available solar generation. The exact behaviour depends on the charger, metering or sensors, inverter setup and configuration.

Where supported and correctly configured, load management can reduce EV charging power when other household loads increase, helping keep total demand within the configured site limit.

The manufacturer lists an IP66 enclosure rating for this charger. The final mounting location should follow the manufacturer's installation requirements and be confirmed by the installer.

A dedicated home EV charger should be installed by a licensed electrician. The installer should confirm the circuit design, switchboard capacity, protection requirements and any applicable local electricity-network requirements.

Key specifications

Estimated installationaround $700–$1,500

Power7 kW

PhaseSingle-phase

Cable7.5m tethered

Weather ratingIP66

Warranty2 years

Solar supportSurplus solar

OCPP—

Load balancingYes

App controlYes

Charger prices are estimates based on publicly available pricing we could verify and may change with retailer offers, promotions and product configuration. Installation is additional.

Typical installation estimate for a straightforward home installation. Longer cable runs, switchboard upgrades, three-phase work, trenching or other site requirements can increase the cost.
